PRODUCT DETAILS
Number of Layers: 6
Board Thickness: 1.4+/-0.1mm
Size: 68mm*147mm
Raw Material: EMC(EM-825)
Min. Aperture: 0.2mm
Surface Treatment: heavy gold
Min. Hole Copper: 20um
Min. Surface Copper: 29.3um
Min. Line Width/Distance: 0.125mm/0.094mm
