Copper Substrate · Strict Quality Selection
-
- LED Automotive Lamp Double-Sided Copper Substrate
- Number of Layers: 2L
- Board Thickness: 1.0-5.0mm
- Surface Treatment: HASL LF/Immersion Gold/OSP
-
- Thermoelectric Separation of Copper Substrate
- Number of Layers: 2L
- Board Thickness: 1.6mm
- Surface Treatment: OSP
-
- Double-Sided Copper Substrate
- Number of Layers: 2L
- Board Thickness: 2.0mm
- Surface Treatment: Immersion Gold
-
- 4L Immersion Gold Copper Substrate
- Number of Layers: 4L
- Board Thickness: 5.6mm
- Surface Treatment: Immersion Gold
-
- Step Copper Substrate
- Number of Layers: 2L
- Board Thickness: 6.5mm
- Surface Treatment: Immersion Gold
-
- 2L EV-Charger Copper Substrate
- Number of Layers: 2L
- Board Thickness: 4.0mm
- Surface Treatment: Immersion Gold
-
- 1.0MM Single-Sided Copper Substrate
- Number of Layers: Single-Sided
- Board Thickness: 1.0mm
- Surface Treatment: OSP
-
- Automotive Lamp Copper Substrate
- Number of Layers: 2L
- Board Thickness: 1.0mm
- Surface Treatment: OSP/Immersion Gold
Copper Substrate· Manufacturing Capability
| Item | Kinji·Copper Substrate·Manufacturing Capabilities |
|---|---|
| Number of Layers | 1 -8 Layers |
| Thermal Conductivity | 1W/mK-12W/mK，Thermoelectric Separation is 398W(Convex Board) |
| Maximum Copper Substrate Size | 1200mm*480mm |
| Minimum Copper Substrate Size | 5mm*5mm |
| Minimum Hole Diameter | 0.6mm |
| Finished Copper Thickness | 1OZ - 3OZ |
| Line Width Spacing | 1OZ : 4mil/5mil、2OZ : 6mil/8mil、3OZ : 10mil/11mil |
Copper Substrate· Advantages
High Thermal Conductivity: The thermal conductivity of the Copper substrate is relatively high, which can quickly conduct heat, form a temperature difference, and improve the thermoelectric conversion efficiency.
Conductivity: Copper substrate can conduct electrons quickly, improve the generation of thermoelectric effect and current output.
Good Mechanical Properties: Copper substrate has high strength and hardness, corrosion resistance is also relatively good, can adapt to a variety of environmental application needs.
Easy to Process: Copper substrates are easy to cut and form, and can be prepared into devices of various shapes and sizes for a variety of applications.
High-Efficiency Ehermoelectric Devices: Copper substrates can be used in combination with thermoelectric potential materials to achieve efficient thermoelectric conversion and energy recovery by optimizing the size of the temperature difference and current.
Copper Substrate· Application
-
Computers
-
Routers
-
Commercial Lights
-
Power Meters
-
ECU
-
Industrial Controllers
-
Switches
-
UV Lamps
Four Core Advantages, Rest Assured to Choose
-
Strictly select raw materials, without quality worries
Strictly select raw materials, without quality worries
Adopt A level raw materials, eliminate defective products, ensure product quality, strictly control production process, in line with international IPC standards. -
Advanced equipment, mature technology
Advanced equipment, mature technology
A full set of automated production equipment, real-time data control throughout the process, effectively ensure delivery on time, to meet the needs of R&D testing. -
Professional team, customized service
Professional team, customized service
With more than 50 high-end technology process team, a variety of special technology process coverage, can provide expedited service, select freely according to your demand. -
Intimate service, without delivery worries
Intimate service, without delivery worries
More than 10 local service offices around the world, providing flexible, high efficient and excellent product delivery services, delivery on time.
