HDI PCB· Quality Optimization

  • 4L 1-Level HDI Medical Display PCB
    Number of Layers: 4L
    Board Thickness: 1.0mm
    Surface Treatment: Immersion Gold
  • 8L 1-Level Communication HDI PCB
    Number of Layers: 8L
    Board Thickness: 1.2mm
    Surface Treatment: Immersion Gold+OSP
  • 6L HDI PCB,FR4(TG175)，1OZ Cu,Immersion Gold(…
    Number of Layers: 6L
    Board Thickness: 1.60mm
    Surface Treatment: Immersion Gold(2u")
  • 6L HDI WIFI Module PCB
    Number of Layers: 6L
    Board Thickness: 0.8mm
    Surface Treatment: Immersion Gold+OSP
  • 8L Impedance HDI PCB
    Number of Layers: 8L
    Board Thickness: 1.6mm
    Surface Treatment: Thick Gold Plating+ENEPIG
  • 12L 5-Level HDI PCB
    Number of Layers: 12L
    Board Thickness: 1.8±0.18mm
    Surface Treatment: Immersion Gold
  • 2-Level HDI Testing PCB
    Number of Layers: 10L
    Board Thickness: 1.3±0.13mm
    Surface Treatment: ENEPIG
  • 4L 1-Level Blind & Buried Hole Board
    Number of Layers: 4L
    Board Thickness: 1.6+/-0.16mm
    Surface Treatment: Immersion Gold

HDI PCB· Manufacturing Capability

Item Kinji·HDI PCB·Manufacturing Capability
Number of Layers 1 - 32 Layers
Board Thickness Inner Core Thickness :0.05mm-1.5mm; Finished Thickness: 0.3mm-3.5mm
Minimum aperture Laser Drill :0.075mm/3mil; Mechanical Drill :0.15mm/6mil
Minimum line width/line distance 0.03mm/0.03mm(1.2mil/1.2mil)
Maximum Machining Size 700mm*610mm
Copper Thickness 1/2OZ - 5OZ
Surface Treatment Electrolytic Nickel/Gold, OSP, HASL, Gold Plating, Immersion Tin
Learn more manufacturing capability Information

HDI PCB· Advantages

High Density: Compared with the traditional PCB board, the wiring density of HDI board is higher, effectively improving the complexity of circuit design, while reducing the volume of the product.

High Reliability: HDI materials has excellent heat resistance, moisture resistance and electrical properties, ensuring the long-term stable operation of electronic equipment.

Excellent Electrical and Thermal Properties: HDI materials has low dielectric constant and low thermal expansion coefficient, which effectively improves the transmission speed of electrical signals and ensures the stable operation of electronic equipment in various environments.

HDI PCB· Application

  • Medical Monitoring

  • Computer Servers

  • Tablet Computers

  • Smart watch

  • Automotive Navigation

  • PLC

  • Industrial Automation Equipment

Four Core Advantages, Rest Assured to Choose

  • Strictly select raw materials, without quality worries

    Strictly select raw materials, without quality worries

    Adopt A level raw materials, eliminate defective products, ensure product quality, strictly control production process, in line with international IPC standards.

  • Advanced equipment, mature technology

    Advanced equipment, mature technology

    A full set of automated production equipment, real-time data control throughout the process, effectively ensure delivery on time, to meet the needs of R&D testing.

  • Professional team, customized service

    Professional team, customized service

    With more than 50 high-end technology process team, a variety of special technology process coverage, can provide expedited service, select freely according to your demand.

  • Intimate service, without delivery worries

    Intimate service, without delivery worries

    More than 10 local service offices around the world, providing flexible, high efficient and excellent product delivery services, delivery on time.
