Aluminum Substrate · Excellent Quality
-
- Automotive Aluminum Substrate LED Board
- Number of Layers: 2L
- Board Thickness: 1.0-2.0mm
- Surface Treatment: OSP
-
- Collapsible Aluminum Substrate
- Number of Layers: Single-Sided
- Board Thickness: 0.4-1.0mm
- Surface Treatment: OSP
-
- 1.2 Meters LED Aluminum Substrate Long Board
- Number of Layers: Single-Sided
- Board Thickness: 1.0mm
- Surface Treatment: HASL/OSP
-
- 2L Aluminum Substrate, 1.6MM, 2OZ Cu
- Number of Layers: 2L
- Board Thickness: 1.6mm
- Surface Treatment: Immersion Gold
-
- Single-Sided LED Aluminum Substrate Light Source Board Customization
- Board Type: Aluminum Substrate
- Number of Layers: Single-Sided
- Board Thickness: 1.6mm
-
- LED Automotive Lamp Aluminum Substrate
- Number of Layers: 2L
- Board Thickness: 1.2mm±0.1mm
- Surface Treatment: OSP
-
- COB (Chip-On-Board) Flip Chip Aluminum Substrate
- Number of Layers: Single-Sided
- Board Thickness: 1.5mm
- Surface Treatment: HASL
-
- 0.6MM Thick Calendered Copper Bent Aluminum Substrate
- Number of Layers: Single-Sided
- Board Thickness: 0.6mm
- Surface Treatment: OSP
Aluminum Substrate· Manufacturing Capability
| Item | Kinji·Aluminum Substrate·Manufacturing Capabilities |
|---|---|
| Finished Copper Thickness | 18um/25um/35um/70um(0.5oz/0.75oz/1oz/2oz) |
| Board Thickness Range | 0.2mm - 5.0mm |
| Maximum Size | Standard：480mm*580mm；Large Size：580mm*1180mm(Support Customization) |
| Board Thickness Tolerance(t≥1.0mm) | ±10% |
| Board Thickness Tolerance(t<1.0mm) | ±0.1mm |
| Thermal Conductivity | 1W/mk - 12W/mk |
| Surface Treatment | Immersion Gold, Immersion Silver, Immersion Tin, OSP |
Aluminum Substrate · Advantages
Efficient Heat Dissipation: The excellent thermal conductivity of the Aluminum substrate can quickly dissipate the heat generated when the electronic equipment is working, ensuring that the electronic equipment works at a lower temperature.
High Mechanical Strength: Aluminum substrate has high mechanical strength and rigidity, can withstand large loads, is not easy to deformation and break, to ensure the stability and reliability during use.
Chemical Stability: The chemical properties of the Aluminum substrate are stable, not easily affected by oxidation, corrosion and etc, can work stably for a long time, and will not cause pollution to the human body and the environment, and has good environmental protection performance.
Aluminum Substrate· Application
-
Frequency Converter
-
LED Lighting
-
Power Supply Equipment
-
Audio Equipment
-
RF Amplifier
-
Sensor
-
DC Converter
-
ECU
-
Communication Module
Four Core Advantages, Rest Assured to Choose
-
Strictly select raw materials, without quality worries
Strictly select raw materials, without quality worries
Adopt A level raw materials, eliminate defective products, ensure product quality, strictly control production process, in line with international IPC standards. -
Advanced equipment, mature technology
Advanced equipment, mature technology
A full set of automated production equipment, real-time data control throughout the process, effectively ensure delivery on time, to meet the needs of R&D testing. -
Professional team, customized service
Professional team, customized service
With more than 50 high-end technology process team, a variety of special technology process coverage, can provide expedited service, select freely according to your demand. -
Intimate service, without delivery worries
Intimate service, without delivery worries
More than 10 local service offices around the world, providing flexible, high efficient and excellent product delivery services, delivery on time.
